1.ELECTRICAL CHARACTERISTICS:

 1.1 WORKING VOLTAGE: 60V DC Max.

 1.2 POWER CURRENT: 1.5A DC Max.

 1.3 SIGNAL CONTACT RESISTANCE:  10 mΩ MAX

     OUTER CONTACT RESISTANCE:  7.5 mΩ MAX

 1.4 INSULATION RESISTANCE:  100 MΩ MIN.

 1.5 IMPEDANCE:  100 Ω.

 1.6 FREQUENCY: DC TO 10G Hz.

 1.7 RETURN LOSS: ≤-30dB @0.01-3G Hz.

                              ≤-25dB @3-6G Hz.

                              ≤-20dB @6-10G Hz.

2.MECHANICAL CHARACTERISTICS:

 2.1 ENGAGEMENT FORCE: 45N MAX.

 2.2 RETENTION FORCE LATCH: 110N MIN.

 2.3 CODING EFFICIENCY: 150N MIN.

 2.4 DURABILITY : 25 CYCLES MIN.

3.ENVIRONMENTAL  CHARACTERISTICS;

 3.1 WORKING TEMPERATURE : -40°~+ 105°C

 3.2 THERMAL SHOCK : DIN EN 60068-2-14
