NOTES:

1.INSULATOR:HIGH TEMPERATURE RESISTANT PLASTIC

            MATERIAL UL94 V-0

            THE COLOUR SHALL BE BASED ON THE

            MATERIAL NUMBER CODE.

2.ACTUATOR:HIGH TEMPERATURE RESISTANT PLASTIC

           MATERIAL UL94 V-0  COLOR:BLACK

3.TERMINAL:COPPER ALLOY

  PLATING:F:GOLD PLATING AT CONTACT AND SOLDER

            AREA OVER ALL NI PLATING

          T:MATTE TIN PLATING OVER ALL NI

            PLATING

4.CURRENT RATING:0.5A AC/DC

5.VOLTAGE RATING:50V AC/DC

6.OPERATING TEMPERATURE RANGE:-55°C~+85°C

7.CONTACT RESISTANCE:100mΩ MAX

8.INSULATION RESISTANCE:500MΩ MIN

9.WITHSTANDING VOLTAGE:250V AC/MINUTE
