Current position：Home > Product Center > Ethernet series > 汽车以太网 ETHERNET CONN R-ETH 2 PORT CABLE CONNECT STRAIGHT JACK
汽车以太网 ETHERNET CONN R-ETH 2 PORT CABLE CONNECT STRAIGHT JACK
Product Part Number：1AEF001W02V*P-00
Product brand：Goldenconn
Product description：1. Characteristic impedance: 100 Ω
2. Frequency: DC to 10GHz
3. Return loss:
≤ -30 dB @ 0 ~ 3GHz
≤-25 dB@ 3GHz ~ 6GHz
≤-20 dB@ 6GHz ~ 10GHz
4. Contact impedance of central needle: ≤ 10 mΩ
External conductor contact impedance: ≤ 7.5 mΩ
5. Voltage endurance: 500VDC
6. Rated voltage: 60V DC
7. Rated current: ≤ 1.5 A DC
8. Insulation resistance: ≥ 1000mΩ
Product parameter

Back to the previous page

Current position：Home > Product Center > Ethernet series > 汽车以太网 ETHERNET CONN R-ETH 2 PORT CABLE CONNECT STRAIGHT JACK
汽车以太网 ETHERNET CONN R-ETH 2 PORT CABLE CONNECT STRAIGHT JACK
汽车以太网 ETHERNET CONN R-ETH 2 PORT CABLE CONNECT STRAIGHT JACK
Product Part Number：1AEF001W02V*P-00
Product brand：Goldenconn
Product description：1. Characteristic impedance: 100 Ω
2. Frequency: DC to 10GHz
3. Return loss:
≤ -30 dB @ 0 ~ 3GHz
≤-25 dB@ 3GHz ~ 6GHz
≤-20 dB@ 6GHz ~ 10GHz
4. Contact impedance of central needle: ≤ 10 mΩ
External conductor contact impedance: ≤ 7.5 mΩ
5. Voltage endurance: 500VDC
6. Rated voltage: 60V DC
7. Rated current: ≤ 1.5 A DC
8. Insulation resistance: ≥ 1000mΩ
3D effect display
Product parameter

Download parameters    Back to the previous page
