1. Rated current (maximum): 5A AC/DC

2. Rated voltage (maximum): 30V AC/DC

3. Contact impedance (maximum): 50m Ω (power PIN)

4. Insulation impedance (minimum): 100 MΩ

5. Voltage withstand test (minimum): 630V AC,  3S, leakage current ＜ 1mA

6. Working temperature:- 40° to +85°；

7. Insertion and extraction force: 5-20N

8. Plug and unplug lifespan of over 10000 times

9. Meet ROHS and REACH requirements

10. Meet U4 requirements
